Sufficient torque XCMG XR160 Rotary Drilling Rig

Power and construction performance

The rated torque of the power head is 160kN · m, the speed is 5-35r/min, it supports multiple gears, and high-speed soil throwing is optional, with high hole forming efficiency; The maximum aperture is 1.5m and the maximum drilling depth is 56m, suitable for building, municipal, and highway bridge pile foundations XCMG.
The Cummins QSB7 electronically controlled turbocharged engine has a power output of 150kW, sufficient power reserve, strong adaptability to high altitude and high temperature working conditions, good global compatibility of accessories, and convenient overseas maintenance.
Support quick switching between oil cylinder pressurization/winch pressurization, expandable long helix, dual power head, pipe rolling machine, down the hole hammer, one machine is suitable for multiple construction methods, and can accommodate both soft and hard formations.

Structure and stability

The double arm large parallelogram amplitude changing mechanism expands the operating support range by 24%, and the whole machine has good anti overturning and minimal construction shaking.
The H-shaped telescopic crawler chassis for rotary excavation, large-diameter slewing support, thick plate reinforced drilling mast, and heavy-duty continuous construction structure have high reliability; After the track is retracted, the whole machine is narrow, making it easy to transport and transfer without the need for large disassembly.
The single row rope structure of the main and auxiliary winches increases the service life of the steel wire rope by 2-4 times, significantly reducing the cost of replacing vulnerable parts.

hydraulic system

Load sensing+total power control hydraulic system, responsive action, smooth composite action, energy-saving and fuel-efficient; Double independent large radiators, no high temperature alarm for continuous operation in high temperature and scorching heat.
