Precise alignment with holes XCMG XR160 Rotary Drill Rig

Power and Drilling Performance

The rated torque of the power head is 160kN · m, the speed is 5-35r/min, and the high-speed soil throwing mode can be selected. It is suitable for building, municipal, and small road and bridge pile foundations, with a maximum aperture of 1.5m and a maximum depth of 56m.
Cummins electronically controlled turbocharged engine, 150kW, with sufficient power reserve and widespread maintenance parts, balancing power and fuel consumption.
Dual pressurization mode: optional hydraulic cylinder pressurization+winch pressurization, suitable for dealing with clay, sand layers, moderately weathered rocks and other geological formations.

Structural stability and durability

Double arm large parallelogram amplitude changing mechanism, with a support range increased by 24% and better anti overturning performance during construction; Special TDP hydraulic telescopic track chassis+large diameter slewing support, the whole machine is stable, and it is easy to transfer after retracting the tracks.
The main and auxiliary winches have a single row rope structure, and the lifespan of the steel wire rope is 2-4 times that of multi-layer ropes, significantly reducing the cost of steel wire rope replacement and minimizing downtime losses.
Double hydraulic oil cooler, suitable for continuous operation in high temperature environments, making it less prone to high temperatures, and friendly for construction in the southern summer.

One machine with multiple uses and strong expandability in construction methods

It can quickly switch between long spiral and dual power head modules, and one device can achieve multiple pile foundation construction methods. It has high cost-effectiveness for leasing and small package projects, and is suitable for projects with variable working conditions.
