| Engine (Brand + Model) | Mitsubishi D06FRC-TAA, Displacement 6.373L |
| Engine Rated Power | 147kW |
| Engine Rated Speed | 2100rpm |
| Max. Pile Diameter | 1500mm |
| Max. Pile Depth | 56m |
| Rotary Head Rated Torque | 155kN·m |
| Rotary Head Speed Range | 5~35rpm |
| Main Winch Lifting Capacity | 160kN |
| Crowd System Crowd Force | 155kN |
| Crowd System Pull-out Force | 160kN |
| Main Winch Max. Line Speed | 80m/min |
| Crowd System Stroke | 4200mm |
| Operating Weight | 48t (48000kg) |
| Overall Dimensions (LWH) | 13085mm × 4100mm × 18590mm (working status) |
Detailed description
The whole machine is 48t and the transportation size is compact. There is no pressure on the construction site of community, village in the city, narrow road and plant foundation. The cost of transfer trailer is low and it is suitable for frequent site change.
The power is distributed as required, the hydraulic matching is optimized, the oil consumption of small and medium-sized pile foundation shift is far less than 200 models, and the cost performance of civil housing construction and municipal piles is outstanding.
The fifth generation power head, thickened mast and luffing structure, high-strength fatigue test, stable construction of soil layer and soft rock, and cheap maintenance accessories.
