Item
|
Value
|
Unit
|
|
Model
|
SR360R
|
-
|
|
Max. Output Torque
|
360
|
kN·m
|
|
Max. Drilling Diameter
|
3000
|
mm
|
|
Max. Drilling Depth (Friction Kelly Bar)
|
100
|
m
|
|
Max. Drilling Depth (Interlocking Kelly Bar)
|
70
|
m
|
|
Rotary Head Speed
|
5–26
|
rpm
|
|
Max. Crowd Force
|
320
|
kN
|
|
Max. Pull-out Force
|
400
|
kN
|
|
Operating Weight
|
98000
|
kg
|
High torque deep pile SANY SR360R Rotary Drilling Rig
Description
Detailed description
Description
Strong rock penetration ability
Can drive hard rock, moderately weathered limestone, thick pebble layer within 60MPa, large triangular amplitude frame, with a 12% increase in overall stability, and controllable verticality of large-diameter deep piles
Fuel saving intelligent
The Sany ADMS electronic control system distributes power according to demand, with a comprehensive fuel consumption of 38-45L/h, saving more than 10% compared to the old model; Equipped with Yiweixun remote positioning, fuel consumption, and fault monitoring
Durable and easy to maintain
Step type drum, single-layer arrangement of machine lock rod steel wire rope, increased service life by 35%; External power head key bar, centralized automatic lubrication, convenient daily maintenance
Wide coverage of working conditions
2.5m large aperture+100m deep hole, suitable for bridge, high-speed rail, and high-rise building pile foundations.
