Energy saving YUCHAI YCR405E Rotary Drilling Rig

YUCHAI YCR405E is a top-level large-scale rotary drilling rig with ultra-strong power, high efficiency and energy saving, equipped with Yuchai’s self-developed core power system and advanced hydraulic control technology. It is suitable for super-large infrastructure projects, deep foundation engineering of high-rise buildings, cross-river bridge pile foundations and other key projects, and can efficiently cope with complex strata such as hard rock, weathered rock and deep soil layers. The detailed specifications are as follows

Core Selling Points

• 405 kN·m ultra-high torque power head + 375-405 kW Yuchai YC6K13 core engine, adopting Yuchai’s advanced power control technology, with sufficient power reserve, which can efficiently break hard rock strata and greatly improve construction efficiency.
• Integrated with Yuchai’s self-developed high-efficiency energy-saving system, referring to the energy-saving technology of IE-POWER hybrid system, the fuel consumption is reduced by 15% compared with similar products, and the operation noise is low, which is more environmentally friendly and economical.
• 100 m max drilling depth (friction rod) and 3000 mm optional drilling diameter, fully meeting the construction needs of super-large infrastructure, deep foundation of high-rise buildings and cross-river bridge pile foundations.
• Adopting advanced hydraulic drive system and double-variable hydraulic motor drive technology, with stable operation, strong load capacity and low failure rate, suitable for long-term continuous heavy-load construction.
• Optional multi-emission standards and flexible transportation configuration, complying with global environmental protection policies; the core engine adopts international top-level components, with reliable quality and suitable for global high-end large-scale engineering markets.

Product Advantages

• Ultra Power Advantage: Equipped with Yuchai YC6K13 high-power engine (optional Cummins X15) and 405 kN·m torque power head, combined with three-input rotary drive, it has stronger excavation force and drilling efficiency, and can cope with various complex strata such as hard rock, weathered rock and deep soil layers.
• Efficiency & Energy Saving Advantage: Integrated with Yuchai’s self-developed energy-saving technology, referring to the IE-POWER system’s energy-saving experience, it realizes real-time power distribution and intelligent energy saving, with low fuel consumption and low noise, effectively reducing long-term operating costs.
• Stability & Reliability Advantage: Adopting heavy-duty box-type mast and double boom lifting structure, with 120-ton operating weight and 900mm wide track plate, it has extremely strong stability and can avoid tilting during ultra-deep and large-diameter drilling; the core components adopt strict quality control, with long service life and low maintenance frequency.
• Global Adaptability Advantage: Optional Euro III/Euro V emission standards and China National Stage IV, meeting the environmental protection requirements of different countries and regions; flexible transportation dimensions and configurable weight, convenient for overseas transportation and on-site transfer, suitable for global key engineering projects.
• Intelligence & Operational Advantage: Equipped with intelligent monitoring system and optimized man-machine interface, it can realize real-time monitoring of construction parameters and equipment working status, with simple operation and easy mastery for operators; the drilling precision is high, ensuring the quality of pile holes in key projects.
