Adapt complex strata sany SR360 Rotary Drill Rig

Core performance advantages (strong rock penetration+large depth)

Top level torque and pressure: 360kN · m power head torque+280-290kN pressure, the strongest configuration in the same class, easily handling hard rocks above 60MPa.

Deep pile capacity: The maximum drilling depth of the friction rod is 100m, the machine lock rod is 65m, and the maximum pile diameter is 2.5m, suitable for ultra deep piles and large-scale foundation engineering.

Rock black technology: automatic pulse pressurization+rock entry adaptive technology, automatically matching torque/pressure according to rock layers, increasing rock entry efficiency by 15%+.

Structural and stability advantages (stability, resistance to construction, no shaking)

Heavy duty chassis: 120 ton self weight+large-span tracks, low center of gravity, wide width, no shaking or tilting during construction.

Five level vibration reduction+truss mast: all-round vibration reduction, mast bending and impact resistance, no cracking for 20000 hours.

Large triangular amplitude: 12% improvement in stability compared to parallelogram structures, and higher accuracy in pile formation in loose formations.

Efficiency and handling advantages (fast, intelligent, easy to drive)

Fast merging of winches: The maximum speed of the main winch is 75m/min, and the auxiliary winch is 70m/min. The efficiency of lifting/lowering the drill is significantly ahead.

Intelligent control: SANY Adams system+EVI intelligent management, fault warning, data recording, adaptive drilling, even beginners can efficiently carry out construction.

Multi mode power head: low speed high torque/high speed low torque/automatic mode with one click switching, suitable for soil layers, rock layers, and gravel layers.

Reliability and maintenance advantages (durable, fuel-efficient, easy to repair)

Heavy load design: 3 sets of motors for the power head and a heavy-duty gearbox, resistant to impact and with a long lifespan; Anti fatigue design of structural components.

Energy saving chassis: Kawasaki negative control hydraulic system, saving 10% -15% fuel compared to competitors.

Maintenance friendly: centralized lubrication, integrated electrical control cabinet, intelligent fault diagnosis, low maintenance and repair costs.

Mobility and safety advantages (flexibility, safety)

Mast can be flattened: lower transportation height, more convenient transition, and better passability.

Safety configuration: winch bottom protection, anti rollover, overload protection, cab vibration reduction, safer construction.
