Low-emission XCMG RIG XR150D-III Rotary Drilling Rig

Low-emission XCMG XR150D-III Rotary Drilling Rig

Description

Item	Value	Unit
Model	XR150D-III	-
Max. Output Torque	150	kN·m
Max. Drilling Diameter	1500	mm
Max. Drilling Depth (Friction Kelly Bar)	56	m
Rotary Head Speed	7–33	rpm
Max. Crowd Force	150	kN
Max. Pull-out Force	150	kN
Main Winch Lifting Capacity	150	kN
Engine Model	Cummins (Guangxi)	-
Engine Rated Power	150 @ 2050	kW/rpm
Operating Weight	49000	kg

Inquire Now

Detailed description

Description

Core Advantages

Eco-Friendly & Low-Emission Performance
Powered by a high-efficiency engine that meets strictEuro III emission standards. Optimized combustion system drastically reduces exhaust pollutants and fuel consumption, aligning with global green construction norms.

High-Efficiency Hydraulic System
Adopts advanced hydraulic control technology for lower energy loss and faster response. Matched with premium imported components to ensure stable power output and consistent drilling efficiency.

Superior Stability & Mobility
Hydraulic retractable crawler chassis delivers outstanding anti-tilting stability for complex worksites. Compact design enables convenient transportation and fast site transfer, saving construction time.

Smart, Safe & User-Friendly
Built-in full-range safety protections and intelligent electronic control system for easier operation. Rugged structure, low wear design and simplified maintenance cut downtime and operating costs.

Wide Applicability & Reliable Quality
Adaptable to diverse geological conditions with flexible drilling configurations. Backed by strict quality inspections and international certifications, ensuring long-term durability in harsh environments.
