| Maximum output torque | 130 kN·m |
| Overall machine weight | 37.5 t |
| Maximum pile diameter | 1300 mm |
| Maximum pile depth | 35 m |
| Engine model | Cummins QSB7-C169G4 |
| Rated power | 126 kW |
| Speed range | 6–32 r/min |
| Maximum pressing force | 120 kN |
| lifting force | 130 kN |
| speed | 78 m/min |
Highly adaptable SUNWARD SWDM130 Rotary Drilling Rig
Description
Detailed description
Description
Invincible transition, transported with poles
The whole machine with drill rod can be directly loaded onto the flatbed without dismantling the mast or waiting for transition. The transportation width is 2.6m and the height is 3.2m, which fully complies with the road width limit.
Specially customized for power towers/building construction
Small body, high torque, perfectly matching the pile type requirements of electric tower foundations, rural self built houses, and small factories. The auxiliary hoist can directly lift the steel cage without the need for an additional crane, saving costs and improving efficiency.
Fuel economy, quick return on investment
National IV Cummins engine+optimized hydraulic system, fuel consumption is 10%~15% lower than the same level. Centralized maintenance points, universal use of vulnerable parts, and low cost of later use.
Intelligent control, simple and easy to operate
Equipped with one click vertical/reverse mast, automatic verticality, drilling depth memory, and fault self diagnosis. Support remote monitoring through the Shanhe Xiangyun APP, making management and maintenance more convenient.
