جهاز حفر دوار TYSIM KR60 عالي التكيف
جهاز حفر دوار TYSIM KR60 عالي التكيف

جهاز حفر دوار TYSIM KR60 عالي التكيف

وصف

طراز المحرك CAT C3.6
القدرة المقدرة للمحرك 82 كيلوواط
سرعة المحرك المقدرة 2000 دورة في الدقيقة
أقصى قطر للحفر 1000 مم
أقصى عمق للحفر 20 مترًا
أقصى عزم دوران دوراني 60 كيلو نيوتن متر
نطاق سرعة الدوران 8-30 دورة في الدقيقة
أقصى قوة سحب للرافعة الرئيسية 60 كيلو نيوتن
أقصى قوة دفع لنظام الحشود 90 كيلو نيوتن
أقصى قوة سحب لنظام الحشود 100 كيلو نيوتن
أقصى سرعة للخط الرئيسي للرافعة 70 م/دقيقة

يشارك :

وصف تفصيلي

وصف

تكلفة الانتقال منخفضة للغاية

The whole machine is transported in one, with a width of less than 2.6 meters. It can be easily accessed from small roads in urban areas or rural construction sites without the need for over limit procedures. The short distance shipping cost is much lower than that of large models.

Dedicated for narrow spaces

Compact body, low working height, suitable for rural self built houses, urban village renovation, mountain photovoltaics, communication tower foundations, and specialized models for micro anchor cable holes.

توفير الوقود وانخفاض تكاليف التشغيل

The small displacement Caterpillar engine has a pure soil construction fuel consumption of only 5-7 L/h, making it easy for individual and small-scale construction sites to recoup their costs; Low failure rate, minimal oil pipe leakage, and high resale value.
